Description

Solar water heater is a system which riveting heat component of sunlight to heat the water of a tank. It is largely used by residential, hospitals, hotels, industries etc. Solar water heater is installed in an open space where it can get adequate sunlight directly and normal water flows through tube/plate & absorbing the heat from the sunlight. Then the hot water is stored in the insulated tank.

We are ISO 9001:2015 certified & MNRE standard manufacturer of solar water heater of both type i.e. ETC & FPC. Available model: 100L/200L/300L & 500L for residential user and 1000L/2000L for commercial/industrial user.

Technical Components

  • Cladding material: GI Powder coated.
  • Material-Tank Mild steel with 4.0mm thickness.
  • Circulation: Thermo siphon.
  • Collectors (Qty): 10 Nos/100L
  • Header size: 25.4 mm.
  • Aperture area: 1.0 sq.m
  • Reflector foil: Aluminium, 50 microns
  • Header material: Copper
  • Riser material: Copper
  • Solar collectors: Selectively coated.
  • Glass: Toughened glass, 4mm thick.
  • Sealing: EPDM rubber.
  • Gaskets: EPDM rubber.
  • Hardware: Stainless steel screws.

Advantages

  • It can save electricity bill up to 90% annually.
  • 24 hours hot water supply.
  • Benchmark temperature range from 60°C to 85°C available.
  • Almost zero maintenance cost.
  • MNRE Standard.
  • 100% GI tank with powder coated.
